Specifications
Self-priming toothed disc crusher is a small, multi-purpose, new type of crusher that can crush all kinds of food, medicine, and seasoning raw materials. It is suitable for grain processing, feed processing, processing of medicinal materials, processing of seasoning products, and For other professional processing, the movement has two types of claws and hammers for users to choose. Different sizes of sieves can be installed according to the needs, and materials with different thickness can be processed.
| Model | EM-9FZ-23 | EM-9FZ- 35 | EM-9FZ-45 |
| Rotating speed | 5000r/min | 3500r/min | 3200r/min |
| Rotor diameter | 230mm | 350mm | 450mm |
| Sieve diameter | 280mm | 424mm | 508mm |
| Sieve size（mm) | 840×100 | 1330×120 | 1600×115 |
| Capacity | ≥200kg/h | ≥800kg/h | ≥1500kg/h |
| Flat tooth（piece） | 4 | 5 | 6 |
| Square tooth（piece） | 6 | 11 | 12 |
| Tons of electricity consumption | ≤22KW.h/t | ≤18KW.h/t | ≤18KW.h/t |
| Voltage | 220V | 380V | 380V |
| Power | 3kw | 11kw | 18.5kw |
| Spare parts | Feed hopper sieve ring sieve (2 sets) | ||
| Machine size（mm) | 700x445x910 | 1140*670*1050 | 1061*1960*1370 |
| Weight | 40kg | 93kg | 140kg |
